LED X-Ray View Box (Premium)

• Slimmest X-Ray viewer with a thickness of 25mm (Just 1 inch)
• High brightness of more than 7500 Lux, exclusive for viewing detail image freely
• Excellent uniformity of luminance which is more than 90%
• Adopt LED light source with life of 100,000 hours
• Free from flickering, hence reduced eye-fatigue
• Inbuilt power supply
• Wall & table mounted.
• 2 years off-site warranty
• Please ask for Customization for modular Operation Theatre.

25 mm Thickness

 Parameters

	Single Film	Double Film	Three Film	Four Film
Sensor Dimmer
View Area (inches L x H)	14 x 17”	28 x 17”	42 x 17”	56 x 17”
External Dimension (MM) L X H X T	505 x 504 x 25 (mm)	884 x 504 x 25 (mm)	1257 x 504 x 25 (mm)	1635 x 504 x 25 (mm)
Light Source	LED	LED	LED	LED
Colour Temp.	8000K	8000K	8000K	8000K
Brightness	>7500 LUX	>7500 LUX	>7500 LUX	>7500 LUX
LED Life	100,000 Hours	100,000 Hours	100,000 Hours	100,000 Hours
Power	AC 100-270V (47-53 HZ)	AC 100-270V (47-53 HZ)	AC 100-270V (47-53 HZ)	AC 100-270V (47-53 HZ)
Power Supply	30W	60W	90W	120W

• Both sizes comes with dimmer (intensity controller) and film sensor (Auto Switch)
• Single Film 1 Dimmer and 1 Sensor
• Double Film 2 Dimmers and 2 Sensors
